Cylinder activation is fingertip controlled, the more the hand lever is engaged the more
the ram movement is accelerated. This allows the operator to control the proper speed for the task.
Not shown
Front safety guard for operator protection (optional).
Safety guard can be removed within a few seconds if necessary.
Hydraulic power-lift for vertical displacement of table.
Cylinder activation is fingertip controlled, the more the hand lever is engaged the more the ram movement is accelerated. This allows the operator to control the proper speed for the task.
Self-locking table design eliminates lateral movement. Standard feature on all H Frame Press models.
The more pressure that you apply to the workpiece, the more rigid the table and frame become.
12" Ram travel allows the operator to do jobs requiring a longer stroke like broaching.
Cylinder activation is fingertip controlled, the more the hand lever is engaged the more the ram movement is accelerated. This allows the operator to control the proper speed for the task.
Electric / Hydraulic operation provides smooth, consistent pressing action.
Quality Baldor motor, low speed.
Low speed pump - quiet, dependable operation.
High capacity 10 GAL. hydraulic oil reservoir.
Power pack conveniently placed out of the way on all models.
All hydraulic and mechanical parts are standard in the industry, and available throughout North America.
OPTIONAL SAFETY KIT
Operation of the safety kit:
When any of the four guards are opened, the press will automatically go to jog mode "low pressure", unless the operator turns the key to the “on” position which will enable the operator to use the press at full pressure with the guards open.
OPTIONAL SAFETY GUARDS
Are avilable for all H Frame Presses.
Press Plate & V Blocks (Option)
TABLE & MATCHED PAIR OF V BlOCKS ARE PRECISION MACHINED.
Adjustable stroke control c/w foot pedal-electric solenoid valve, speed control and electric control panel (optional).
Flat ram nose can be easily changed to allow the user to adapt the press to a specific job.
Cylinder activation is fingertip controlled, the more the hand lever is engaged the more
the ram movement is accelerated. This allows the operator to control the proper speed for the task.
Not shown
Front safety guard for operator protection (optional).
Safety guard can be removed within a few seconds if necessary.
